Buy the GLORYTECH GTT2506E 2.5 ton lithium-battery electric telehandler with 6 m lifting height, 3.3 m forward reach, 70.66 kWh battery system and 1.5-hour fast charging. The GLORYTECH GTT2506E Electric Telehandler is a zero-emission, low-noise material-handling solution for construction, agriculture, warehouses and industrial jobsites. With a rated load capacity of 2,500 kg, a maximum lifting height of 6.0 m and a maximum forward reach of 3.3 m, it combines clean electric power with full 4WD traction and three steering modes for confined spaces.
| Parameter | Specification |
|---|---|
| Rated Load Capacity | 2,500 kg |
| Lift Capacity at Full Height | 2,000 kg |
| Lift Capacity at Full Reach | 800 kg |
| Max Lift Height | 6,000 mm |
| Max Forward Reach | 3,300 mm |
| Reach at Max Lift Height | 450 mm |
| Bucket Breakout Force | 4,205 N |
| Operating Weight | 6,600 kg |
| Overall Length (with forks) | 5,200 mm |
| Overall Width (over tyres) | 2,129 mm |
| Overall Height | 2,180 mm |
| Wheelbase | 2,297 mm |
| Front Track | 2,100 mm |
| Ground Clearance | 380 mm |
| Outside Turning Radius | 4,360 mm |
| Cab Inside Width | 800 mm |
| Tyre | 12-16.5 vacuum tyre |
| Fork Length | 1,070 mm |
| Load Center | 500 mm on fork |
| Steering Modes | Front-wheel / four-wheel / crab steering |
| Drive Type | 4WD |
| Lithium Battery System | 307.2 V / 70.66 kWh (2 x 153.6 V / 35.33 kWh packs) |
| Battery Pack Configuration | 1P48S (1P16S modules) |
| Operating Voltage Range | 120-175.2 V (per pack) |
| Battery Energy Density | >=150 Wh/kg |
| Battery Protection Rating | IP68 / IP6K9K |
| Battery Thermal Management | Liquid cooling + electric heating |
| Travel Motor | 35 kW |
| Pump Motor | 30 kW |
| Drive Motor Rated Voltage | 350 V |
| Drive Motor Power | 50 / 100 kW |
| Drive Motor Cooling | Water cooling |
| Drive Motor Protection | IP67 |
| Motor Controller | 165 Arms continuous, IP68 |
| Gearbox Max Input Torque | 450 Nm |
| Gearbox Max Input Speed | 12,000 rpm |
| Gearbox Ratio Range | 3.6 - 4.5 |
| Gearbox Cooling | Circulating oil cooling |
| Travel / Pump Controllers | 153.6 V / 450 A |
| Charger | 153.6 V / 200 A |
| Charging Time | 1.5 hours |
| Hydraulic Oil Tank | 115 L |
| Warranty | 1 year or 1,200 working hours |
