The ARPT self-propelled material retrieval machine lifts both operator and load to a 4 m platform height (6 m working height), making high-level order picking and stock retrieval faster and safer. Its compact 1.4 m chassis and tight turning circle are built for warehouse aisles, and the quiet electric drive delivers clean, emission-free operation with a 300 kg platform capacity.
| Model | GT Material Retrieval Machine |
|---|---|
| Type | Self-Propelled Electric |
| Manufacturer | GLORYTECH |
| Max Working Height | 6m |
| Max Platform Height | 4m |
| Platform Dimensions (L×W) | 0.6 × 0.6m |
| Length (Stowed) | 1.4m |
| Width (Stowed) | 0.7m |
| Height (Stowed) | 1.8m |
| Wheelbase | 0.95m |
| Machine Weight | 650kg |
| Platform Occupancy | 1 person |
| Platform Capacity | 300kg |
| Extension Deck Capacity | 100kg |
| Drive Speed (Stowed) | 3-5km/h |
| Drive Gradeability | 20% |
| Turning Radius (Inside/Outside) | 0 / 1.4m |
| Drive & Steer Mode | 2×2 |
| Tire Type | Solid Non-Marking |
| Tire Size | φ230×80mm |
| Drive System | Self-Propelled Electric |
| Engine / Battery | 24V/180Ah |
| Engine Power | 1.2kW |
| Fuel Tank Volume | N/A |
| Hydraulic Oil Capacity | 8L |
| Certification | CE |
| Application | Indoor & Outdoor Aerial Work |
